Onpin Air Screwdriver OP-310 Series EN ISO 11148-6:2012 - Max Torque 240Nm, 8000rpm, Alloy Steel Motor
The Onpin OP-310 Series Air Screwdriver (including models OP-310Q and OP-310F) operates at a standard working pressure of 90 psi (6.2 bar), delivering a free speed of 8000 rpm, working torque of 60 Nm, and a maximum torque of 240 Nm for 6 ~ 8 mm screw capacity. It features an alloy steel motor set, a 2-step push start trigger, side exhaust, and an oil-in-the-front cap design for extended service life. Equipped with an integrated hook design for spring balancers and available in Q or F bit types, it is ideal for heavy-productive industries such as rattan, carpentry, electrical appliances, motors, aluminum fabrication, and hardware production.
- OP-310 Series
- 310 Series
- OP-310Q Series
- OP-310F Series
- OP-310Q
- OP-310F
- 310Q
- 310F
- air screwdriver
- pneumatic screwdriver
- Onpin air screwdriver
- air impact screwdriver
- industrial air screwdriver
Design file download links:
PDF fileDescription
Specification
The Onpin OP-310 Series Air Screwdriver (including OP-310Q and OP-310F models) is a high-performance industrial pneumatic fastening tool designed for heavy-duty assembly applications. Powered by standard air pressure at 90 psi (6.2 bar), it generates a maximum torque of 240 Nm at 8000 rpm free speed for fast and efficient screw driving.
Key Features of Onpin OP-310 Series
- Durable Alloy Steel Motor: Built with an alloy steel material motor set to ensure exceptional durability under heavy-duty usage.
- High Torque & Speed: Delivers High Torque, High Speed combined with High impact frequency for maximized productivity.
- Versatile Anvil Options: Features two bit holder options: Type Q (model OP-310Q) and Type F (model OP-310F).
- 2-Step Push Start Trigger: Equipped with a 2 step push start trigger for enhanced control during fastening operations.
- Side Exhaust System: Incorporates a Side exhaust design to direct exhaust air away from the immediate work area.
- Extended Tool Life: Features an Oil-in-the-front cap design for continuous internal lubrication and prolonged operational life.
- Ergonomic Safety Design: Integrated Hook design compatible with spring balancers to reduce operator fatigue and enhance safety.
Technical Specifications of Onpin OP-310 Series
- Brand: Onpin
- Series Model: OP-310 Series (Detail models: OP-310Q, OP-310F)
- Normative Standards: EN ISO 11148-6:2012, Machinery Directive 2006/42/EC
- Screw Size Capacity: 6 ~ 8 mm
- Working Torque: 60 Nm (44 ft-lb)
- MAX. Torque: 240 Nm (177 ft-lb)
- Free Speed: 8,000 rpm
- Air Consumption: 254 l/min (9 cfm)
- Overall Length: 200 mm (7.87 inch)
- Air Inlet Size: 1/4 P.T
- Net Weight: 1.06 kg (2.38 lb)
- Sound Level: 97 dB(A)
- Operating Air Pressure: 90 psi (6.2 bar / 6.3 kg/cm²)
- Bit Type: Type Q (Model OP-310Q) / Type F (Model OP-310F)
Industrial Applications of Onpin OP-310 Series
- Furniture & Woodworking: Specifically designed for heavy productive rattan products and carpentry assembly.
- Electrical & Motor Manufacturing: Ideal for housing assembly in electrical appliances and electric motor manufacturing.
- Aluminum & Hardware Fabrication: Widely used in aluminum structure assembly and general hardware production lines.
