/ Onpin OP-406LB (3/8") Two Hammer Impact Wrench - Working Torque 100Nm, Free Speed 8000rpm, Bolt Capacity M12
Onpin OP-406LB (3/8") Two Hammer Impact Wrench - Working Torque 100Nm, Free Speed 8000rpm, Bolt Capacity M12
The Onpin OP-406LB (3/8") Two Hammer Impact Wrench features a quick chuck design for effortless bit changes in heavy-productive industries. It supports convenient one-hand operation with an integrated forward and reverse switch alongside an efficient handle exhaust system. Delivering a robust working torque of 100 Nm (max torque 190 Nm) and a free speed of 8000 rpm, it ensures high-performance fastening for M12 bolts. Operating at a standard air pressure of 90 psi (6.2 bar), this pneumatic tool provides reliable durability for professional assembly workflows.
- OP-406LB
- 406LB
- 01-104-01
- 02-200-04
- 02-201-05
- 02-201-10
- 02-203-03
- 03-700-04
- 03-700-07
- 04-700-03
- 04-702-04
- 04-702-07
- 05-701-05
- 06-700-01
- 08-701-05
- 12-700-05
- 13-401-01
- 13-700-03
- 14-701-01
- 14-701-02
- 15-702-04
- 17-302-02
- 18-502-04
- 18-702-04
- 19-702-02
- 24-706-03
- 25-702-08
- 26-703-06
- 30-304-01
- 31-703-01
- 35-708-04
- 36-503-13
- 37-503-05
- 38-504-04
- 39-504-01
- 40-701-03
- 41-703-02
- 43-702-03
- 45-703-04
- 51-309-01
- 51-502-01
- 51-802-01
- 52-501-02
- 52-702-06
- 54-701-03
- 74-706-03
- 75-605-03
- 70-608-03
- pneumatic impact wrench
- air impact wrench 3/8
- two hammer impact wrench
- air wrench op-406lb
- onpin air impact wrench
Design file download links:
PDF fileDescription
Specification
What is Hông Bing / Onpin OP-406LB?
The Onpin OP-406LB is a high-performance pneumatic impact wrench powered by compressed air, featuring a durable two-hammer impact mechanism designed to deliver consistent peak torque and maximum efficiency in heavy-duty industrial assembly lines. The tool operates by converting pneumatic pressure into rapid rotary impacts, allowing technicians to efficiently fasten and loosen heavy-duty threaded fasteners with precision.
Key Features of Hông Bing / Onpin OP-406LB
- Advanced Two Hammer impact mechanism delivers balanced striking force, reduces vibration, and extends tool durability under continuous heavy loads.
- One-hand operation design equipped with an accessible forward & reverse switch for enhanced directional control.
- Handle exhaust system channels exhaust air away from the operator and work surface to maintain a clean working environment.
- Integrated quick chuck allows for rapid and effortless bit or socket changes, minimizing operational downtime.
- Compact and lightweight construction featuring a net weight of 1.2 kg and an overall length of 160 mm to minimize operator fatigue in confined spaces.
Technical Specifications of Hông Bing / Onpin OP-406LB
- Model: OP-406LB
- Anvil Size: 3/8 inch
- Bolt Size Capacity: M12
- Working Torque: 100 Nm (74 ft-lb)
- MAX Torque: 190 Nm (140 ft-lb)
- Free Speed: 8000 rpm
- Air Consumption: 283 l/min (10 cfm)
- Overall Length: 160 mm (6.3 inch)
- Air Inlet P.T: 1/4 inch
- Net Weight: 1.2 kg (2.65 lb)
- Sound Level: 87 dB(A)
- Recommended Air Pressure: 6.2 bar (90 psi)
Industrial Applications of Hông Bing / Onpin OP-406LB
- Heavy-productive manufacturing industries including rattan and carpentry workshops.
- Electric motor assembly and industrial electrical equipment manufacturing.
- Aluminum structure fabrication, mechanical hardware assembly, and precision engineering lines.
- Heavy-duty industrial workstations requiring dependable pneumatic fastening performance.
