Airtac 3V2M Series Pneumatic Solenoid Valve Manifold, 3/2 Way Direct Acting, 1/8”, AC/DC Voltage

Specification:

The valve operates with filtered compressed air (40µm) and adopts a 3-port, 2-position structure, available in both normally closed (NC) and normally open (NO) types. The 3V2M Series comes with a 1/8 inch port size and a durable aluminum alloy body, ensuring long service life and corrosion resistance.

A key advantage of the 3V2M Series is its sub-base mounting design, allowing multiple valves to be combined into a valve manifold with centralized or separated air supply and exhaust, effectively saving space and simplifying piping and wiring.

The valve operates reliably at pressures from 0 to 0.8 MPa, with a proof pressure of 1.2 MPa, and requires no lubrication, reducing maintenance costs. It supports multiple voltage options including AC220V, AC110V, AC24V, DC24V, and DC12V, and features IP65 protection, making it suitable for demanding industrial environments.

For easy commissioning and troubleshooting, the valve is equipped with a manual override function, enabling quick testing during installation and maintenance.

🔹 Key Features

1. 3/2 way modular pneumatic solenoid valve, direct acting
2. Sub-base mounting for manifold assembly and expansion
3. Available in NC and NO configurations
4. 1/8 inch port, aluminum alloy body
5. No lubrication required, low maintenance
6. Multiple AC/DC voltage options, IP65 protection
7. Ideal for industrial pneumatic automation systems

🔹 Applications

1. Industrial automation production lines
2. Packaging and assembly machines
3. Pneumatic cylinder control systems
4. Pneumatic valve manifolds
