/ Air Drill Onpin OP-D8410 - 13mm Chuck, 0.6 HP, 1000 RPM, Composite Housing, Reversible
Air Drill Onpin OP-D8410 - 13mm Chuck, 0.6 HP, 1000 RPM, Composite Housing, Reversible
The Onpin OP-D8410 industrial air drill delivers 0.6 HP power in a lightweight 1.62 kg composite housing, featuring a 13 mm (1/2 inch) chuck with a 3/8-24UNF spindle thread. Powered by a gear-driven mechanism, it provides a free speed of 1000 rpm and a stall torque of 14.9 Nm under standard 90 psi / 6.2 bar operating pressure. It includes a stepless trigger for smooth speed control, a positioning-type forward/reverse switch for one-handed operation, and a noise-reducing bottom exhaust operating at 88 dB(A) with 283 l/min air consumption via a 1/4 P.T inlet.
- OP-D8410
- OPD8410
- OP D8410
- Onpin OP-D8410
- Onpin OPD8410
- Onpin OP D8410
- OP-D84 series
- OP-D8410 model
- 0.6 HP composite housing air drill 1000rpm
- 1/2 inch reversible pneumatic drill 14.9Nm
- Onpin industrial air drill 1000rpm 13mm chuck
- gear driven composite body air drill
- stepless trigger high speed pneumatic drill
Design file download links:
Other fileDescription
Specification OP-D8410
The Onpin OP-11AK pneumatic tapper is a professional industrial-grade tapping tool operating at a standard air pressure of 90 psi (6.2 bar). Powered by a gear-driven mechanism featuring a B12 spindle taper and a slip-clutch collet chuck, it delivers a free speed of 150 rpm. It is engineered to create precise threads on aluminum and brass (3-12mm) or steel (3-8mm), optimizing the threading process while significantly reducing tap breakage risks in mechanical manufacturing lines.
Key Features of Onpin OP-11AK
- Precision Gear-Driven Mechanism: Ensures stable torque transmission, high load capacity, and enhanced mechanical durability under demanding operational conditions.
- Slip-Collet Chuck & B12 Spindle Taper: Securely clamps taps and ensures smooth directional reversal and tap retraction, effectively preventing tap breakage.
- Reversible Switch & Bottom Exhaust: Allows fast directional changes while directing exhaust airflow downward to minimize operating noise and workspace dust disturbance.
- Balancer Hanging Ring: Compatible with spring balancers to alleviate operator fatigue and protect the tool from accidental drops during long shifts.
Technical Specifications of Onpin OP-11AK
- Brand: Onpin
- Model: OP-11AK
- Operating Air Pressure: 90 psi (6.2 bar / 6.3 kg/cm²)
- Tapping Capacity (Aluminum / Brass): 3 - 12 mm
- Tapping Capacity (Steel): 3 - 8 mm
- Free Speed: 150 rpm
- Spindle Taper: B12
- Air Inlet: 1/4 P.T
- Reversible Function: Yes (o)
Industrial Applications of Onpin OP-11AK
- Machinery Manufacturing & Precision Engineering: Thread tapping on machinery frames, structural plates, and metal housings.
- Automotive & Motorcycle Parts Production: Machining and threading engine components, transmission housings, and aluminum parts.
- Mold & Die Industry: Precision thread creation on steel and aluminum mold plates for injection molding and stamping dies.
- General Maintenance & Industrial Assembly: Facility maintenance, threaded hole restoration, and plant equipment servicing.
