AIRTAC GA Series Gas Distribution Block – Pneumatic Air Flow Divider

Specification:

The AIRTAC GA Series gas-distribution block is a dedicated pneumatic air flow divider designed to be installed between GA Series regulators (or filter & regulator units) and lubricators. It efficiently divides compressed air into multiple paths, improving flexibility and air supply management in industrial pneumatic systems.

The GA Series distribution block allows one air path to pass through the lubricator for oil lubrication, while another path delivers clean, non-lubricated air directly to equipment, meeting different pneumatic requirements within the same system. Its precisely machined internal structure ensures stable airflow and minimal pressure loss.

Available in multiple port sizes from 1/8” to 1”, the GA Series gas-distribution block is suitable for small to large pneumatic systems. Optional mounting brackets (T-type, L-type, U-type) provide flexible installation options, making system assembly and maintenance more convenient.

Key Features

1. Dedicated gas distribution block for GA Series pneumatic systems
2. Divides compressed air into multiple output paths
3. Supports both lubricated and non-lubricated air supply
4. Robust construction with high durability
5. Low pressure loss and stable airflow
6. Multiple port sizes and mounting bracket options

Technical Specifications

1. Series: AIRTAC GA Gas-Distribution Block
2. Working medium: Compressed air
3. Operating pressure: 0 ~ 1.0 MPa
4. Proof pressure: 1.5 MPa
5. Operating temperature: -20 ~ 70°C
6. Number of air ways: 4 ways
7. Port size: 1/8”, 1/4”, 3/8”, 1/2”, 3/4”, 1”

Applications

1. Industrial pneumatic systems
2. Automated production lines
3. GA Series air preparation units
4. Manufacturing, assembly, and packaging equipment
5. Multi-device air distribution systems
